Northtech Model NT 820EL Heavy-Duty Chain Drive Series Double Surface Planer
Machine Available
Stock #52500N
New- Northtech Model NT 820EL Heavy-Duty Chain Drive Series Double Surface Planer
- CUTTERHEADS
- 50HP Top, 50HP Bottom
- Dual (8) Row Helical Cutterhead with double sided 30 x 12 x 2.5mm inserts
- 5000RPM solid steel cutterheads with Class 7 NSK bearings
- PRODUCT DIMENSIONS
- Working width 820mm (32”)
- 16” min working length
- Thickness range 10mm - 160mm (3/8” - 6-1/4”)
- FEED SYSTEM
- 7.5HP + 10HP inverter feed motor
- Elevation motor: 2HP
- Carpet feeding spike system with 1900 spikes
- Feed speed 8~25 M/min (25-80FPM)
- FEATURES
- Digital control panel with 3 oversized inverter feed control amp meters
- Chrome bed plate
- Amperage requirement: 230V @ 288AMP / 460V @ 144AMP
- (3) 6” dust ports requiring 981 CFM @ each point of extraction
- UL/CE Certified electrical components
- Includes operator’s manual and parts book
- Machine dimensions: 121” L x 77” W x 69” H
- Packing dimensions: 124”L x 81”W x 77”H
- Machine gross / net weight: 15,433lbs. / 16,535 lbs
- One year parts warranty
- All machines are tested stateside prior to shipment providing trouble-free start up.
