Timesavers Model 3341-45-1333 Four Head 52" Orbital
Machine Available
Stock #71230N
New- Timesavers Model 3341-45-1333 Four Head 52" Orbital Sander
- Specifications:
- Abrasive size combination head: 52" x 103"
- Main motors: 30, 7.5, 7.5, 7.5HP
- Maximum width stock: 51"
- Minimum part length with vacuum bed: 6"x6"
- Maximum thickness opening: 6"
- Infeed loading area: 24"
- Feed speed: 15-45 FPM
- Approximate full load amps at 460 volt: 120
- Passline height: 41" Constant
- Dust extraction: 9450 CFM (5” static pressure)
- Compressed air usage: 6 CFM@90psi
- Standard Features:
- Dual Action Sanding Head: (1st head position)
- Twin Pad Dual Motion Orbital Head:(2 , 3 & 4th position)
- Dual Infeed and Dual Outfeed Holddown Rolls:
- Variable Speed Conveyor Drive
- Centralized Control Panel
- Spare Platen Assemblies
- Main Motor Percentage Watt Meter
- Motorized Thickness Adjustment
- Four Jack Bed Construction
- Infeed Stop Bar
- Hour Meter
- Infeed Conveyor Extension
- U.L. Listed Controls
- Vacuum Conveyor Bed
- Timesavers Graphical Interface HMI
- A/C Frequency
- Factory Start-up and Training
