Laguna Model Fusion F3 Tablesaw
Machine Available
Stock #90230N
New- Laguna Model Fusion F3 Tablesaw
- The new Laguna Fusion line was developed for demanding woodworkers. Designed around quality components with an emphasis on superior dust collection enhanced by utilizing over/under collection & sealed bottoms. All models are equipped with precision fence, plus the F2 & F3 feature the Hi/Low aluminum extrusion known from European saws. Permanently lubricated bearings & Acme screws are part of the internal DNA. Fusion 3 is the big brother to Fusion 2. • cast iron trunnion • upgraded handles & Miter Gauge • outfield table equipped with double miter slots • built with an extra heavy-duty cabinet, 36" still fence On board storage of all accessories. The Fusion F3 features professional cabinet saws built with no compromises.
- Machine Specifications
- Power Requirements: 220V-1PH-60HZ
- Amperage (FLA): 14 AMP
- Motor Power: 3 HP
- Motor Speed: 3450 RPM
- Starter Switch: Magnetic
- Plug Included: 6-15
- Circuit Breaker Req.: 220V - 25 AMP
- Receptacle Req. : 6-15
- Rip Capacity: 36" STD, 52" OPTION
- Blade Size: 10"
- Vertical Cut Height: 3 1/8”
- 45° Cut Height: 2 1/8"
- Tilt: 0-45° Left
- Min. Kerf: 3mm ~1/8" (actual: 0.1875")
- Max. Kerf (Dado Blade): 13/16"
- Arbor Speed: 4500 RPM
- Arbor Diameter: 5/8"
- Mitre Slot: 3/4" to 1" T
- Throat Plate: Zero Clearance Square Composite, w/ adjustment
- Fence: Double Rail Cam Action
