Baker Model P.A.Q. Single Head Band Resaw

• Baker Model P.A.Q. Single Head Band Resaw
• Baker single cut "PAQ" band resaw with return, electric complete with a totally enclosed fan cooled 20HP motor, Nema 12 enclosure, starter, motor overload protection and all is prewired. Machine also complete with a variable speed hydraulic feed system including the pump, tank, flow control, valves and plumbing.
• Number of Heads: 1
• Number of Blades: 1
• Number of Cuts: 1
• Guides: Baker's Revolutionary Octaguide System (8x more wear life)
• Main Drive Motors: One 20 HP TEFC (11 kw TEFC)
• Electrical: All 3-phase voltages available
• NEMA 12 enclosure with starter and overload protection
• Feedworks: Hydraulic pump, driven from head motor, complete with flow control valve, filter, and tank; rough-top conveyor belt and non-powered hold-down included
• Feed Speed: Variable, 0 - 120 fpm (6.1 - 36.6 mpm)
• Conveyor Width: 6 in. (152 mm)
• Material Capacity: 8 in. x 12 in. (203 mm x 305 mm)
• Band Blades: One 0.035 in. x 1 in. x 13 ft. 2 in. hardback
• Band Wheels: Two 28 in. diameter, dynamically balanced, all steel band wheel, providing fly-wheel effect while cutting
• Blade Tensioning: Mechanical, spring
• Optional simple slide return system
• Optional powered hold-down
• Optional 12" wide powered slide return conveyor
