Doucet Model BT3 BTWB3 Modular Platform Return Conveyor
Machine Available
Stock #44553
Used- Doucet Model BT3 BTWB3 Modular Platform Return Conveyor
- One (1) Return Conveyor, Basic Model BTWB336, including:
- 41" wide x 5' long receiving conveyor for an effective width of 36"
- 41" wide x 13' long return conveyor
- 24" transfer module
- 17 belts
- Transfer bypass switch
- Three non-motorized infeed rollers
- 5" Stroke option on reception conveyor working height (instead of 2" standard) with automatic reception height adjustment
- Compressed air requirement: 10 cfm @ 90 psi
- Right or Left hand return
- Operating Speed: 30-90 FPM
- Minimum part sizes on conveyors: 4" x 12"
- Maximum panel sizes feeding long sides: 36" x 96"
- Maximum Batch loading: 36" x 5'
- Note that items are located in Canada and will have associated duty/import fees
- Customer to provide customs broker information
